Freewing Electronic Retract for 5.1mm Diameter Shafts - Type D ET8402

SKU: ET8402

Freewing Electronic Retract for 5.1mm Diameter Shafts - Type D

Normaler Preis: ^€23⁵⁹ (VAT inc.)
Sonderpreis: ^€23⁵⁹
Normaler Preis: ^€0⁰⁰; (Save €-23.59)
Einzelpreis: pro

In stock

Die Menge muss 1 oder mehr sein

Overview
Q&A

Electronic Retract for 5.1mm Diameter Shafts - Type D from Freewing - ET8402

Click here to view special instructions to prevent jammed retract pins.

Note: These retracts are used on the T-45's sold after July 2019.

For the nose gear on the following Freewing aircraft:

Avanti S 80mm
T-45 90mm
Eurofighter 2023 version 90mm

Product Specifications:

Gear Material	Nylon/ABS
Operating Voltage Range	4.8V - 6V
Speed (4.8V)	3.5 sec @ 90 deg
Speed (6V)	3.2 sec @ 90 deg
Torque (4.8V)	13.0 kg/cm (180 oz/in)
Torque (6V)	15.5 kg/cm (215 oz/in)
Current Draw at Idle (4.8V)	130mA
Current Draw at Idle (6.0V)	150mA
Maximum Load Current (4.8V)	1900mA
Maximum Load Current (6.0V)	2300mA
Current Draw Operating (No Load)	10mA
Dimensions (L x W x H)	75.5 x 38 x 50mm
Weight	66g (2.32oz)
Lead Length	320mm
