GF30 30cc Four-Stroke Engine from NGH - NGH-GF30
Here at Motion RC we are pleased to present our customers with the NGH line of gas engines. NGH have become known for building quality gas engines that offer light weight, power and reliability at a very affordable price. They are manufactured and designed from scratch for model aircraft, they are not modified chainsaw or similar types of engines that have been in the past, they are purpose made.
Following the success of the GF38 NGH have launched an all new 30cc fourstroke. That it is a little bit smaller it is a perfect replacement for a 1.20 - 1.50 FS glow. Complete with a Walbro pumped carb and Rcexl ignition it is designed for petrol. It also comes with a factory built muffler system.
Features:
- Four stroke sound and efficiency
- Twin roller CNC conrod
- Twin ringed pistons
- Angle adjustable exhaust system with baffler
- Velocity Stack installed on the carb for improved throttle response
- Compact and powerful design, ideal for scale model installations
- Genuine Walbro carburetor for reliable running and easy tuning
- Blue anodized 'beam' style engine mounts included
- RCEXL Ignition with automatic advancing system
- Ideal for 20-25cc 2 stroke class models
- Powerful output and excellent reliability
- Attractive blue anodized prop hub
- Locking prop nut included
- Clean burning, no more oily residue on your model
- Purpose made, specifically designed from the ground up and optimized for gas powered RC planes
Includes:
- NGH GF30 30cc Four-Stroke Engine
- CDI
- Exhaust Pipe
- Connecting Line
- Spark Plug
- Mounting Bracket Base
- Screw Set
- English Manual
Product Detail
What's Included
Please note: All RC model gas-powered engines require the user to properly set up, tune, and maintain the engine in order to achieve consistent peak performance. You will need to break-in the engine initially, then perform routine maintenance including cleaning the engine, lubricating its seals and moving parts, and adjusting the fuel mixture and valves as necessary. This is considered the normal responsibility of owning and operating an RC gas engine. For further questions, please contact Customer Support.
Product Specifications:
Displacement |
29.91cc |
Bore |
36mm |
Stroke |
29.4mm |
RPM Range |
1,600-8,500 RPM |
Mix Output |
2.68HP / 9,000 RPM |
Engine Weight |
1160g |
Overall Weight |
1365g |
Ignition Power |
DC 4.8-8.4V 1000mAh |
Recommended Propeller |
15x10 / 16x8-10 / 17x6-10 |
Fuel |
93 Unleaded Petrol + fully synthetic 2T lubricants |
Lubricant Ratio |
35:1 |
Spare Parts
Product Spare Parts
1 - 32 of 62 results
Q&A
Product questions & answers
NOTE: Questions submitted on this page are answered by customers who have previously purchased this item. If you have a support related question that requires immediate assistance, please visit our Help Center
Support
Product support
Product Manuals:
- NGH GF30 30cc Four-Stroke Engine Instruction Manual
- NGH GF30 30cc Four-Stroke Engine Exploded Diagram
If you need any additional assistance, please visit the Motion RC Help Center
