ZOHD Dart XL EV 1000mm (39.37") - PNP from ZOHD - ZOH10042
The ZOHD DART XL "Enhanced" Version is an updated version of the ZOHD Dart XL Extreme. Vortex generators, detachable wings, and vertical fins are what give this airplane an outstanding lift performance! The "Enhanced" version of this PNP comes with a new motor mount that is stronger and durable. Also added is a GPS bay cover, built-in carbon fiber rod inside the fuselage, optimized airfoil, extended dock for the flight controller, extended plywood for battery, extra ball linkage inside the package, and a built-in carbon fiber strip inside the rear hatch for just to list some of the improvements.
Built with BEPP, a biodegradable and durable foam.
Visit the Official ZOHD Dart XL EV 1000mm Discussion Thread on HobbySquawk.com for additional photos, videos, reviews, and customer Q&A.
 |
Easy Assembly and Transport The detachable wing and vertical fins makes the Dart XL easy to transport. |
 |
Durable BEPP Construction Molded by tough BEPP biodegradable material, built-in CF spar for enhancement, stable flying capability and impact resistance. |
 |
Large Battery Bay The Dart XL incorporates a large battery bay for your chosen FPV equipment and electronics. |
 |
Camera Compatibility The multi-camera nose is compatible with 99% of the FPV and HD cameras in the market: Runcam HD, 2, 3S, Swift, Split, GoPro H4-5-6-7, Session, and much more! |
Features:
- Small size airframe optimized for long-range FPV and portability
- Carefully chosen airfoil gives the aircraft an incredible lift power and excellent handling
- Detachable wing and vertical fins make it portable for easy transport
- Light-weight composite hard nose for better protection of your expensive camera gear
- The multi-camera nose is compatible with 99% of the FPV and HD cameras in the market: Runcam HD, 2, 3S, Swift, Split, GoPro H4-5-6-7, Session, and much more!
- Reversed wingtips provide more lift force and ensure a efficient wing surface
- Vortex generators for improving lift efficiency and gain higher control at low speeds
- Load plenty of FPV equipment, large battery/gyro thanks to a huge equipment bay
- Computer-designed optimized airflow pod that maximizes cooling, reducing the risk of crashes from overheated electronics
- Impact-resistant protective cover for the main wing's leading edge and landing skids
- Built-in carbon fiber tube inside main wings for enhanced performance and rigidity
- Exclusive VTX / RX bays with excellent airflow and away from interference
Includes:
- ZOHD Dart XL EV 1000mm (39.37") - PNP
Requires:
- 4 Channel radio - select a minimum 4 channel radio from our Radio Collection
- 4 Channel receiver - select a minimum 4 channel receiver from our Receiver Collection
- 4 Cell 14.8V 2500 - 3300 mAh LiPo Battery - we recommend the Admiral 3000mAh 4S 14.8V 35C LiPo Battery with XT60 Connector
- 4 Cell compatible battery charger - select a minimum 4 cell (4S) charger from our Charger Collection
Product Specifications:
Model Scale |
N/A |
Wingspan |
1000mm / 39.3in |
Length |
596mm / 23.4in |
Empty Weight |
706g / 24.9oz |
CG (Center of Gravity) |
Refer to the manual |
Power System |
2216-1300Kv Brushless Outrunner Motor |
Electronic Speed Control |
40A |
Propeller / EDF |
9x4.5 |
Servos |
|
Landing Gear |
None |
Required Battery |
4 Cell 14.8V 3000-3300 mAh LiPo Battery (required) |
Required Radio |
4 Channel 2.4GHz (required) |
Ailerons |
Elevons |
Elevator |
Elevons |
Rudder |
No |
Flaps |
No |
Lights |
No |
Hinge Type |
Foam |
Material |
BEPP Foam |
Skill Level |
Intermediate |
Build Time |
1 Hour |
Recommended Environment |
Outdoors |
